As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly. Its heating rate is 10-100 times faster than that of the traditional furnace.
Application
Experimental and production of biomass, coal, plastics, rubber, organic waste, etc.
Overview
Ultra-temperature Microwave Muffle Furnace is a kind of air atmosphere microwave fast heating high temperature furnace. It’s particularly suitable for high temperature sintering of oxide structure ceramics or transparent ceramics, like alumina, yttrium oxide, zirconium oxide.
It is consisted of microwave heating system, heat shaped cavity, programmable control system, microwave shielding structure, touch screen operation, special thermal insulation module and crucible. It’s controlled by PLC control with touch screen operation: automatic, manual and thermostatical control methods; 40 programmable technology curves available; curve real-time display; data storage and export.
Technical Parameter
| Model | Voltage | Rated power | Microwave rated power | Max. temperature (°C) | Working temperature | Temperature rising rate | Heating zone | Furnace dimension |
| CE-MU1200C-S | 220V | 2.5 | 1.5 | 1200 | 1100 | ≤100 | 150*120*83(2L) | 560*600*700 |
| CE-MU1600C-S | 220V | 2.5 | 1.5 | 1600 | 1550 | ≤100 | 120*70*80 | 560*600*1200 |
| CE-MU1200C-M | 220V | 5 | 3 | 1200 | 1100 | ≤100 | 220*140*105 | 650*700*800 |
| CE-MU1600C-M | 220V | 5 | 3 | 1600 | 1550 | ≤100 | 150*120*83(2L) | 650*700*1200 |
| CE-MU1750C-M | 220V | 5 | 3 | 1700 | 1650 | ≤100 | 100*100*80 | 650*700*1200 |
Features
1. Fast temperature rising rate with max. 100°C/min.
2. 7 inch touch screen to make operation simple.
3. Max. temperature up to 1750°C
4. Insulation fibre lightweight structure to save energy and realize high efficiency.
5. Small furnace dimension with floor occupation ≤0.5m²
6. Less microwave leakage (≤0.05mw/cm²) which is much less than national standard(≤5mw/cm²)
For more information, please contact us
EasyFashion is the multifaceted manufacturer of atomization powder manufacturing equipment and thermal processing equipment. We take pride in offering diversified product range which comprises powder production equipment, sintering furnaces,heat treatment furnaces etc.
