As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly. Its heating rate is 10-100 times faster than that of the traditional furnace.
Application
Experimental and production of biomass, coal, plastics, rubber, organic waste, etc.
Overview
As a kind of lifting microwave fast heating high temperature furnace, microwave zirconia teeth sintering furnace is particularly suitable for the sintering of zirconia teeth, which can save energy greatly and improve productivity.
Technical Parameter
| Model | Voltage | Rated power | Microwave rated power | Max. temperature | Working temperature | Temperature rising rate | Heating zone | Furnace dimension |
| V | KW | KW | ℃ | ℃ | ℃/min | mm | W*H*L（mm） | |
| CE-ZT1600C-S | 220V | 5 | 3 | 1600 | 1550 | ≤100 | Ø150*100(1.8L) | 550*750*1700 |
| CE-LI1600C-S | 220V | 5 | 3 | 1650 | 1600 | ≤100 | Ø150*100(1.8L) | 550*750*1700 |
| CE-LI1700C-S | 220V | 5 | 3 | 1700 | 1650 | ≤100 | Ø130*80(1L) | 550*750*1700 |
Features
1. Fast temperature rising rate with max. 100°C/min.
2. Small microwave power 3KW
3. 7 inch touch screen to make operation simple.
4. Furnace cavity is round so temperature is more uniform.
5. Big loading capacity (zirconia teeth) and fast sintering of longbridge teeth
6. Automatic lifting tray, simple loading/unloading materials.
7. Insulation fibre lightweight structure to save energy and realize high efficiency.
8. Small furnace dimension with floor occupation ≤0.5m²
9. Less microwave leakage (≤0.05mw/cm²) which is much less than national standard(≤5mw/cm²)
For more information, please contact us
EasyFashion is the multifaceted manufacturer of atomization powder manufacturing equipment and thermal processing equipment. We take pride in offering diversified product range which comprises powder production equipment, sintering furnaces,heat treatment furnaces etc.
