Microwave Vacuum Furnace

Overview

As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly. Its heating rate is 10-100 times faster than that of the traditional furnace.

Microwave vacuum furnace is a type of microwave rapid heating high temperature vacuum sintering furnace. Adopt two-speed pump combination, the vacuum degree can be reach 10-4. Can be process not only with variety of atmosphere sintering but also high vacuum degree sintering. Apply to variety of material sintering, raised efficiency experiment and products quality substantially.

Technical Parameter

Model	Voltage	Rated power	Microwave rated power	Max. temperature	Working temperature	Temperature rising rate	Heating zone	Furnace dimension
Model	V	KW	KW	℃	℃	℃/min	mm	WHL（mm）
CE-VA1600C-M	380V	12	6	1600	1550	≤100	Ø180*120(2L)	130018002000
CE-VA1700C-M	380V	12	6	1600	1550	≤100	Ø150*120	130018002000
CE-VA1750C-M	380V	12	6	1700	1650	≤100	Ø120*100	130018002000

Features

1. Fast temperature rising rate with max. 100℃/min.

2. 7 inch touch screen to make operation simple.

3. Good performance of homogeneity, the material appears dynamic condition stirring in the furnace.

4. Vacuumize, sintering with atmosphere protecting

5. Insulation fibre lightweight structure to save energy and realize high efficiency.

6. Less microwave leakage (≤0.01mw/cm²) which is much less than national standard(≤5mw/cm²)
