Microwave High Temperature Lifting Furnace

As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly. Its heating rate is 10-100 times faster than that of the traditional furnace.

Application

Experimental and production of biomass, coal, plastics, rubber, organic waste,etc..

Inquire Now Next Product

Overview

Microwave high temperature lifting furnace is particularly suitable for the sintering of zirconia teeth, for the sintering and reduction of powder metallurgical products, and for fast degreasing, which can save energy greatly and improve quality.

It is consisted of microwave heating system, heat shaped cavity, programmable control system, microwave shielding structure, touch screen operation, lifting device, special thermal insulation module and crucible. It’s controlled by PLC control with touch screen operation: automatic, manual and thermostatical control methods; 40 programmable technology curves available; curve real-time display; data storage and export.

Technical Parameter

Model	Voltage	Rated power	Microwave rated power	Max. temperature	Working temperature	Temperature rising rate	Heating zone	Furnace dimension
Model	V	KW	KW	℃	℃	℃/min	mm	WHL（mm）
CE-ZT1600C-S	220V	5	3	1600	1550	≤100	Ø150*100(1.8L)	5507501700
CE-LI1600C-S	220V	5	3	1650	1600	≤100	Ø150*100(1.8L)	5507501700
CE-LI1700C-S	220V	5	3	1700	1650	≤100	Ø130*80(1L)	5507501700

Features

1. Fast temperature rising rate with max. 100°C/min.

2. 7 inch touch screen to make operation simple.

3. Furnace cavity is round so temperature is more uniform.

4. Automatic lifting tray, simple loading/unloading materials.

5. Sintering condition can be air or other atmosphere.

6. Insulation fibre lightweight structure to save energy and realize high efficiency.

7. Small furnace dimension with floor occupation ≤0.5m²

8. Less microwave leakage (≤0.05mw/cm²) which is much less than national standard(≤5mw/cm²)
