As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly. Its heating rate is 10-100 times faster than that of the traditional furnace.
Application
Continuous graphene microwave reduction furnace is a type of microwave rapid heating atmosphere continuous reduction puffing furnace. Apply to reduce puffing at the moment of graphene oxide. Produce high quality graphene, has function of continuous produce, daily output is 5000~20000g.
Overview
As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly. Its heating rate is 10-100 times faster than that of the traditional furnace.
Technical Parameter
| Model | Voltage | Rated power | Microwave rated power | Max. temperature | Working temperature | Temperature rising rate | Heating zone | Furnace dimension |
| V | KW | KW | ℃ | ℃ | ℃/min | mm | W*H*L（mm） | |
| CE-GR1000C-S | 380V | 5 | 3 | 1000 | 900 | ≤50 | Ø130*180(2.4L) | 1500*600*1300 |
| CE-GR1000C-M | 380V | 15 | 9 | 1000 | 900 | ≤30 | Ø230*700(30L) | 3000*1200*2200 |
| CE-RP1000C-M | 380V | 15 | 9 | 1000 | 900 | ≤30 | Ø230*700(30L) | 3000*1200*2200 |
Features
1. Fast temperature rising rate with max. 500℃/min.
2. 7 inch touch screen to make operation simple.
3. Insulation fibre lightweight structure to save energy and realize high efficiency.
4. Atmosphere protection, atmosphere controllable
5. Less microwave leakage (≤0.05mw/cm²) which is much less than national standard(≤5mw/cm²)
For more information, please contact us
EasyFashion is the multifaceted manufacturer of atomization powder manufacturing equipment and thermal processing equipment. We take pride in offering diversified product range which comprises powder production equipment, sintering furnaces,heat treatment furnaces etc.
