Microwave High Pressure Composition Caldron

Applications

Experimental and production of biomass, coal, plastics, rubber, organic waste, etc.


Overview

As a kind of advanced heating technology in the world currently, microwave heating makes use of microwave penetration and selective heating characteristics to heat the overall material inside the insulation layer directly and rapidly. Its heating rate is 10-100 times faster than that of the traditional furnace.

Microwave high pressure composition caldron applied to petrochemical engineering, biomedicine, material science, geology chemical, environmental sciences, center of disease control and prevention, food science, commodity inspection, etc..

Microwave high pressure composition caldron jecket material is pressure vessel, material of dissolve cup is teflon. Fasten the cover with body then can be sealed, the performance of sealed is secular stability without leakage. The maximum temperature is 210℃;The maximum pressure is 3Mpa.


Technical parameter

ModelVoltageRated powerMicrowave rated
 power
Max.  temperatureWorking
 temperature
Temperature
rising rate
Heating zoneFurnace
dimension
V
KWKW℃/minmmW*H*L(mm)
CE-PCK200C-S220V2.51.5210200≤10(1L)600*600*1200
CE-PAK200C-S220V2.51.5210200≤10(1L)600*600*1200
CE-PSK200C-S220V2.51.5210200≤10(1L)600*600*1200


Features

1. Fast temperature rising rate with max. 10℃/min.

2. Small power, microwave power 1.5KW.

3. 7 inch touch screen to make operation simple.

4. Inside of the caldron has a stirring and rapid speed cooling coil.

5. Can reaction under high pressure of strong acid and strong base.

6. Caldron cover is liftable and rotatable, has function of feeding and discharging on line.

7. Maintain microwave heating and electric heating in the same time, powerful.

8. The dimension of equipment is small, occupation of land≤0.5m²

9. Less microwave leakage (≤0.05mw/cm²) which is much less than national standard(≤5mw/cm²)
