The working principle of wire electric explosion method powder production equipment: in a certain medium (such as inert gas, water, etc.) environment, when the strong pulse current passes through the conductor wire, the physical state of the conductor material itself changes sharply, rapidly vaporizes, and then condenses into nucleation, so as to obtain a certain particle size range of powder.
Application
Wire electric explosion method powder production technology is widely used in producing a variety of nano powder materials, according to the principle of electric explosion technology, the material used for electric explosion must be a good conductive material, so the general metal, alloy, intermetallic compounds and metal oxides can be made powder by electric explosion method.
Overview
The working principle of wire electric explosion method powder production equipment: in a certain medium (such as inert gas, water, etc.) environment, when the strong pulse current passes through the conductor wire, the physical state of the conductor material itself changes sharply, rapidly vaporizes, and then condenses into nucleation, so as to obtain a certain particle size range of powder.
Advantages
Wire electric explosion method powder production equipment is mainly used to produce various nano-powders.
Wire electric explosion method powder production technology has the following advantages:
① High efficiency of energy conversion: It is easy to convert electrical energy into heat energy by relying on the resistance of the wire in the discharge circuit.
② The particle size distribution of the prepared powder is more uniform and high purity: pulse discharge can gasification the entire metal wire at the same time, the gasification effect is more uniform, and the surrounding environmental media can be controlled to ensure the high purity of the nanoparticle (the purity of metal nanomaterials can reach 99%).
③ Adjustable process parameters: the particle size can be effectively controlled by adjusting the capacitance, charging voltage and the size of the explosive wire.
④ Strong versatility: the electric explosion method can prepare nano powder materials with a wide particle size range.
Main Functions
We can provide various types of wire electric explosion method powder production equipment.
Technical Parameter
| Model | EF-WEEM-M | EF-WEEM-P |
| Diameter of conductor wire（mm） | 0.1-0.2 | 0.3-0.4 |
| Production capacity（g/h） | ≥50 | ≥100 |
| Yield of powder | Particle size -100nm: ≥50% | |
| Power supply | 380V 50Hz Three phase | |
| Ultimate vacuum degree | 6.67*10-³Pa | |
| Maximum output voltage of the power supply | 50kV | |
| Control mode | Industrial control computer or PLC | |
| Operating interface | Touch-tone or Touch-screen | |
Components
Wire electric explosion method powder production is mainly composed of electric explosion additives, powder collection and treatment system, inflation system, electric explosion power supply, control system, water cooling system, vacuum system, electrical control system, etc.
Others
The main factors affecting the size of nanoparticles prepared by electric explosion method can be summarized as follows:
(1) Circuit parameters: capacitor storage energy, voltage and other circuit parameters;
(2) Material factors: material factors such as conductor material characteristics, length, diameter, and initial crystal structure;
(3) Environmental factors: the type of medium, pressure, temperature and other environmental factors in the electric explosion chamber.
For more information, please contact us
EasyFashion is the multifaceted manufacturer of atomization powder manufacturing equipment and thermal processing equipment. We take pride in offering diversified product range which comprises powder production equipment, sintering furnaces,heat treatment furnaces etc.
