The mixed gas generated is mainly used as protection atmosphere in powder metallurgy reduction, sintering, metal heat treatment, electronics, chemistry industry and ceramics. Because of low cost of gas generating, this series of ammonia decomposition generator is specially suitable to be used as accessory equipment of industries mentioned above.
Overview
This series of ammonia decomposition generator is composed by decomposition machine, purifier and electric control system. This machine decomposes ammonia into a kind of mixed gas which includes 75% hydrogen and 25% nitrogen.
Technical Parameter
| Type | EF-AFQ5 | EF-AFQ10 | EF-AFQ20 | EF-AFQ30 | EF-AFQ40 |
| Rated gas output(Nm3/h) | 5 | 10 | 20 | 30 | 40 |
| Rated ammonia consumption (kg/h) | 2.0 | 4.0 | 8 | 12 | 16 |
| Rated heating power of generator (kw) | 6 | 12 | 29 | 39 | 50 |
| Rated heating power of purifier (kw) | 2 | 4 | 6 | 8 | 10 |
| Rated furnace temperature of generator(°C) | ≤800 | ||||
| Recycling heating temperature of purifier(°C) | 250 | ||||
| Rated power voltage (V) | 380 | ||||
| Dew point of gas purified(°C) | ≤-60 | ||||
| Remnant ammonia content of gas purified (PPM) | ≤10 | ||||
| Catalyzer | Nickel catalyst | ||||
Features
1. Small investment
2. Reliable performance and long service life
3. Heating element
4. Thermal insulation material
5. Electrical control
6. Depressurization system
7. Purification system
8. Simple installation
9. Easy operation and maintenance
10. High safety
For more information, please contact us
EasyFashion is the multifaceted manufacturer of atomization powder manufacturing equipment and thermal processing equipment. We take pride in offering diversified product range which comprises powder production equipment, sintering furnaces,heat treatment furnaces etc.
